LG 50PC5D - Page 26

- 27 -
C884 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C885 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C886 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C887 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C888 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C889 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C890 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C891 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C892 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C893 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C894 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C895 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C896 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C897 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C898 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C899 0CC100BKF1A "Capacitor,Ceramic,Chip" 0402N100J500LT 10pF 5%
C9022 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C905 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C906 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C910 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C911 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C912 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
C916 0CK104BF56A "Capacitor,Ceramic,Chip" C1005X7R104KET 100nF 1
D400 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D403 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D404 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D600 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D602 0DD184009AA Diode Assembly KDS184 KDS184 TP KEC -
D603 0DSON00138A "Diode,Schottky" MMBD301LT1G 600MV 30V
D801 0DR340009AA "Diode,Schottky" MBRS340 525MV 40V 4A 0
D800 0DS226009AA "Diode,Switching" KDS226 1.2V 85V 300MA
D401 0DRSE00038A "Diode,TVS" SDC15 1.3V 14.3VTO16.4
D402 0DRSE00038A "Diode,TVS" SDC15 1.3V 14.3VTO16.4
ZD732 EAH33945901 "Diode,TVS" CDS3C30GTH 30V 50V 120
ZD733 EAH33945901 "Diode,TVS" CDS3C30GTH 30V 50V 120
ZD101 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD102 0DZ560009DA "Diode,Zener" UDZS5.6B 5.6V 5.49TO5.
ZD600 0DZDI00078A "Diode,Zener" BZT52C3V3S-F 3.3V 3.1T
ZD700 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD701 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD702 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD703 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD704 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD705 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD706 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD707 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD708 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD709 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD710 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD711 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD712 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD713 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD714 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD715 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD716 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD717 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD718 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD719 0DZRM00218A "Diode,Zener" UDZS8.2B 8.2V 8.02TO8.
ZD720 0DZRM00218A "Diode,Zener" UDZS8.2B 8.2V 8.02TO8.
ZD721 0DZRM00218A "Diode,Zener" UDZS8.2B 8.2V 8.02TO8.
ZD722 0DZRM00218A "Diode,Zener" UDZS8.2B 8.2V 8.02TO8.
ZD723 0DZRM00218A "Diode,Zener" UDZS8.2B 8.2V 8.02TO8.
ZD724 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD725 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD726 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD727 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD728 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD729 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD730 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD731 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD734 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD735 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD736 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD737 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD738 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD739 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD746 0DZRM00218A "Diode,Zener" UDZS8.2B 8.2V 8.02TO8.
ZD747 0DZRM00218A "Diode,Zener" UDZS8.2B 8.2V 8.02TO8.
ZD748 0DZRM00218A "Diode,Zener" UDZS8.2B 8.2V 8.02TO8.
ZD749 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD750 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD751 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD752 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD753 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
ZD754 0DZRM00178A "Diode,Zener" UDZS5.1B 5.1V 4.98TO5.
IC502 0IPRPCI013A "IC,A/D Converter" CS5340-CZZR 1.7TO5.25V
IC200 EAN38015402 "IC,Analog Switch" BD2051AFJ 2.7TO5.5V 10
IC600 EAN39310001 "IC,Analog Switch" PI3HDMI341ART 3.135 TO
IC501 EAN32404601 "IC,Audio Amplifier" NTP3000 7TO30V 5.5V 0.
IC500 0IPRP00665A "IC,Bus Controller" TEA6420D 8TO10.2V 8mA
IC401 0ISTLPH026A "IC,CMOS" 74LVC14APW 1.2TO3.6V 0
IC408 0ISTL00024A "IC,CMOS" MC14053BDR2G 3TO18V 0.
IC805 EAN31513601 "IC,DC,DC Converter" SC4519STRT 2.6V to 16V
IC300 0IMMRHY057E "IC,DDR SDRAM" HY5DU561622ETP-D43 256
IC302 0IMMRHY057E "IC,DDR SDRAM" HY5DU561622ETP-D43 256
IC102 0IMMRCS012D "IC,EEPROM" CAT24C08WI-GT3-26753 8
IC403 0IMCRAL021A "IC,EEPROM" AT24C512W-10SU-2.7 512
IC406 0IMCRAL006A "IC,EEPROM" AT24C16AN-10SU-2.7 16K
IC601 0IMMRAL014D "IC,EEPROM" AT24C02BN-SH-T 2KBIT 2
IC603 0IMMRAL014D "IC,EEPROM" AT24C02BN-SH-T 2KBIT 2
IC701 0IMMRAL014D "IC,EEPROM" AT24C02BN-SH-T 2KBIT 2
IC900 0IMI623200B "IC,I/O Support Chip" M62320FP(SOP) 4.5TO5.5
IC808 0IPRPFA015B "IC,Image Filter" "FMS6400CS1X,LF 4.75VTO"
IC404 0IPMGA0010A "IC,LDO Voltage Regulator" AZ1117H-3.3 4.75TO10V
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
DIODEs
ICs
