LG 50PC5D - Page 27

- 28 -
IC802 0IPMGA0010A "IC,LDO Voltage Regulator" AZ1117H-3.3 4.75TO10V
IC803 0IPMGS1006B "IC,LDO Voltage Regulator" SC1566I5M25TRT 2.2V~5.
IC804 0IPMGA0010A "IC,LDO Voltage Regulator" AZ1117H-3.3 4.75TO10V
IC807 0IPMG00049A "IC,LDO Voltage Regulator" AZ1117H-1.8TR/E1[H13A]
IC901 0IPMGKE032A "IC,LDO Voltage Regulator" KIA78R09F 10TO25V 9V 8
IC902 0IPMGKE032A "IC,LDO Voltage Regulator" KIA78R09F 10TO25V 9V 8
IC504 0ISTL00029A "IC,OP Amplifier" MC33078DR2G +-5TO+-18V
IC402 EAN39038801 "IC,Tx/Rx" ADM3232EARNZ 3VTO5.5V
IC100 0IPRP00702C "IC,Video Processors" BCM3552KFEB5G 1.14VTO1
IC400 0IKE702900G "IC,Voltage Detector" KIA7029AF -0.3TO15V 2.
IC405 0IKE702900G "IC,Voltage Detector" KIA7029AF -0.3TO15V 2.
IC304 0IPMG78391A "IC,Voltage Regulator" SC2595STR 2.3TO5V 0 0W
IC800 0IMCRSH001A "IC,Voltage Regulator" PQ05DZ1U 6TO16V 5V 8W
IC801 0IMCRSH001A "IC,Voltage Regulator" PQ05DZ1U 6TO16V 5V 8W
IC806 EAN32662801 "IC,Voltage Regulator" KA7809ERTM 35V to 40V
B101 0LCML00003B "Filter,Bead" MLB-201209-0120P-N2 12
B102 0LCML00003B "Filter,Bead" MLB-201209-0120P-N2 12
B103 0LCML00003B "Filter,Bead" MLB-201209-0120P-N2 12
L100 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L101 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L102 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L103 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L104 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L105 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L1100 6210TCE001E "Filter,Bead" HB-1M2012-800JT(H:1mm)
L1212 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L200 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L201 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L202 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L203 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L205 6210VC0006A "Filter,Bead" FBMH3216 HM501NT 500OH
L207 6210TCE001E "Filter,Bead" HB-1M2012-800JT(H:1mm)
L208 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L211 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L300 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L400 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L401 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L402 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L403 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L404 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L405 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L406 6210TCE001G "Filter,Bead" HH-1M3216-501JT 500OHM
L416 6210TCE001E "Filter,Bead" HB-1M2012-800JT(H:1mm)
L500 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L501 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L502 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L503 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L508 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L509 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L510 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L511 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L512 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L513 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L514 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L515 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L517 6210TCE001G "Filter,Bead" HH-1M3216-501JT 500OHM
L600 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L601 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L602 6210TCE001Z "Filter,Bead" HH-1M2012-600JT 60OHM
L603 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L604 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L605 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L606 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L607 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L608 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L609 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L610 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L612 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L613 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L614 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L615 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L616 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L617 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L618 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L619 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L620 6200J00005F "Filter,Bead" HB-1M1608-102JT 1000OH
L800 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L801 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L802 6210TCE001E "Filter,Bead" HB-1M2012-800JT(H:1mm)
L804 6210TCE001E "Filter,Bead" HB-1M2012-800JT(H:1mm)
L806 6210TCE001E "Filter,Bead" HB-1M2012-800JT(H:1mm)
L808 0LCML00003B "Filter,Bead" MLB-201209-0120P-N2 12
L808 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L809 6210TCE001E "Filter,Bead" HB-1M2012-800JT(H:1mm)
L810 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L811 EAM38058401 "Filter,Bead" CB4532UK121E 120OHM 4.
L812 EAM38058401 "Filter,Bead" CB4532UK121E 120OHM 4.
L813 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L814 EAM38058401 "Filter,Bead" CB4532UK121E 120OHM 4.
L815 6200J00005N "Filter,Bead" HH-1M2012-121JT(H:1mm)
L816 0LCML00003B "Filter,Bead" MLB-201209-0120P-N2 12
L816 6210TCE001S "Filter,Bead" HU-1M2012-121 120OHM 2
L902 0LCML00003B "Filter,Bead" MLB-201209-0120P-N2 12
L903 0LCML00003B "Filter,Bead" MLB-201209-0120P-N2 12
F1 6200JB8013A "Filter,Ferrite Core" 6200JB8013A 80OHM 20.5
F2 6210VH0001A "Filter,Ferrite Core" 6210VH0001A 50OHM 25MM
F3 6210VH0004A "Filter,Ferrite Core" 6210VH0004A 100OHM 30M
F4 6210VH0004B "Filter,Ferrite Core" ZCAT1518-0730-M- K 65O
L703 EAM31315201 "Filter,LCR" LCF41P060-TM LPF(EMI)
L707 EAM31315201 "Filter,LCR" LCF41P060-TM LPF(EMI)
L708 EAM31315201 "Filter,LCR" LCF41P060-TM LPF(EMI)
L709 EAM31315201 "Filter,LCR" LCF41P060-TM LPF(EMI)
L710 EAM31315201 "Filter,LCR" LCF41P060-TM LPF(EMI)
L711 EAM31315201 "Filter,LCR" LCF41P060-TM LPF(EMI)
L805 6200J000123 "Filter,LCR" NFE31PT222Z1E9L LPF(EM
L407 0LC2000005K "Inductor,Multilayer,Chip" FI-D2012-223KJT(CE) 22
L408 0LC2000005K "Inductor,Multilayer,Chip" FI-D2012-223KJT(CE) 22
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
COILs & FILTERs & INDUCTORs
