5.8. Miracast/Widi Input
5.8.1. 3D Manual
No. Resolution H-freq(kHz) V-freq.(kHz) 3D input proposed mode
1 1024*768p - 30/60 2D to 3D,Side-by-side ,
Top-and-Bottom
2 1280*720p
3 1920*1080p
4 Others - 2D to 3D
5.8.2. RF 3D Input(DTV)
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed 3D input proposed mode
1 1280*720 45.000 60 74.25 HDTV 720P 2D to 3D, Side by Side, Top & Bottom
2 1920*1080 33.75 60 74.25 HDTV 1080I 2D to 3D, Side by Side, Top & Bottom
5.9. 2D to 3D Conversion(RF 3D Input(DTV))
No INPUT Freq Resolution
1 Digital TV / Analog TV 2D Support freq 2D Support resolution
2 HDMI 2D Support freq 2D Support resolution
3 Component 2D Support freq 2D Support resolution
4 Composite 2D Support freq 2D Support resolution
5 USB 2D Support freq 2D Support resolution
No Side by Side Top & Bottom Checkerboard Single Frame
Sequential
Frame Packing 2D to 3D
