19
PREPARATION
1
LAN
Network connection for Netflix, Yahoo! TV
Widgets, etc (for USA).
Also used for video, photo and music files on
a local network.
2
HDMI/DVI IN, HDMI IN
Digital Connection.
Supports HD video and Digital audio. Doesn’t
support 480i.
Accepts DVI video using an adapter or HDMI
to DVI cable (not included).
3
RGB IN (PC)
Analog PC Connection. Uses a D-sub 15 pin
cable (VGA cable).
AUDIO IN (RGB/DVI)
0.32 cm (1/8 inch) headphone jack for analog
PC audio input.
4
RS-232C IN (SERVICE ONLY), SERVICE ONLY
This port is used for service.
5
OPTICAL DIGITAL AUDIO OUT
Digital optical audio output for use with amps
and home theater systems.
Note: In standby mode, this port doesn’t work.
6
AV (Audio/Video) IN
Analog composite connection. Supports
standard definition video only (480i).
7
ANTENNA/CABLE IN
Connect over-the-air or cable signals to this
jack.
8
COMPONENT IN
Analog Connection.
Supports HD.
Uses a red, green, and blue cable for video &
red and white for audio.
9
WIRELESS CONTROL
Connect the Wireless Ready Dongle to the TV
to control the external input devices con-
nected to Media Box wirelessly.
10
USB INPUT
Used for viewing photos, watching movies
and listening to MP3s.
11
HEADPHONE
0.32 cm (1/8 inch) headphone jack
Impedance 16 Ω , Maximum audio out 15 mW
12
Power Cord or Socket
For operation with AC power.
Caution: Never attempt to operate the TV on
DC power.
13
REMOTE CONTROL IN
For a wired remote control.
