LG 55LM660S-ZA User Manual

Interconnection - 1
1
Main PCB
2
Power Board
3
Tact key PCB
T-con Driver
1
2
3
4
5
Main / LPB 24Pin cable
Main / Module EPI cable
50& 50PIN
LED driver / PSU
10Pin (IR+Touch) Cable
SPK Cable
Local Dimming Cable
[PCBs]
[Cables]
6
12
3
1
2
3
4
5
6
xxLM760S-ZA
7
RF Assy Cable
7
8
WIFI Assy Cable
8
45
4
RF Assy
5
WIFI Assy
Copyright © 2012 LG Electronics. Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only

LG 55LM660S-ZA Specifications

General

Screen Size	55 inches
Display Type	LCD
Smart TV	Yes
HDMI Ports	4
USB Ports	3
Wi-Fi	Yes
Ethernet	Yes
Audio Output	20W
Backlight Technology	LED
3D Technology	Yes
Refresh Rate	100Hz
Operating System	LG Smart TV
Resolution	1920 x 1080
Weight	19.5 kg
