LG 55LM6700 Service Manual

- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5. External Input Support Format
5.1. Component(Y, Pb, Pr)
5.2. RGB Input (PC) : RGB-PC EDID DATA : Refer to adjust specification.
No. Resolution H-freq(kHz) V-freq(Hz) Remark
1. 720*480i 15.73 59.94 13.500 SDTV, DVD 480I(525I)
2 720*480i 15.73 60.00 13.514 SDTV, DVD 480I(525I)
3. 720*576i 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50Hz
4 720*480p 31.47 59.94 27.000 SDTV 480P
5 720*480p 31.50 60.00 27.027 SDTV 480P
6 720*576p 31.25 50.00 27.000 SDTV 576P 50Hz
7 1280*720 44.96 59.94 74.176 HDTV 720P
8 1280*720 45.00 60.00 74.250 HDTV 720P
9 1280*720 37.50 50.00 74.25 HDTV 720P 50Hz
10 1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz,
11 1920*1080 33.72 59.94 74.176 HDTV 1080I
12 1920*1080 33.75 60.00 74.25 HDTV 1080I
13 1920*1080 26.97 23.976 63.296 HDTV 1080P
14 1920*1080 27.00 24.000 63.36 HDTV 1080P
15 1920*1080 33.71 29.97 79.120 HDTV 1080P
16 1920*1080 33.75 30.00 79.20 HDTV 1080P
17 1920*1080 56.25 50 148.5 HDTV 1080P
18 1920*1080 67.432 59.94 148.350 HDTV 1080P
19 1920*1080 67.5 60.00 148.5 HDTV 1080P
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock (MHz) Proposed Remark
1. 640*350 31.468 70.09 25.17 EGA
2 720*400 31.469 70.08 28.32 DOS
3. 640*480 31.469 59.94 25.17 VESA(VGA)
4 800*600 37.879 60.317 40 VESA(SVGA)
5 1024*768 48.363 60.004 65 VESA(XGA)
6 1360*768 47.712 60.015 84.75 VESA(WXGA)
7 1920*1080 67.5 60.00 138.50 WUXGA (CEA 861D) FHD Only

LG 55LM6700 Specifications

General

Display diagonal	55 \
Native refresh rate	60 Hz
LED backlighting type	Edge-LED
Supported video modes	1080i, 1080p, 720p
Contrast ratio (dynamic)	8000000:1
Display diagonal (metric)	139.7 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	TruMotion 120 Hz
3D	Yes
3D type	Passive
Supported 3D technologies	FPR 3D
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Audio system	Dolby
RMS rated power	20 W
Number of speakers	2
DVI port	No
HDMI ports quantity	4
DVI-D ports quantity	0
Common interface (CI)	-
USB 2.0 ports quantity	3
Component video (YPbPr/YCbCr) in	1
Smart modes	Cinema, Game, Standard, Vivid
Lifestyle apps	Skype
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Sustainability certificates	ENERGY STAR
Package depth	201 mm
Package width	1560 mm
Package height	879 mm
Package weight	30645 g

Weight and Dimensions

Depth (with stand)	330 mm
Height (with stand)	795 mm
Weight (with stand)	25015 g
Depth (without stand)	33 mm
Width (without stand)	1232 mm
Height (without stand)	724 mm
Weight (without stand)	21338 g
