68 Free Joint Multi Air Conditioner
Exploded View & Replacement Parts List
PART No.
A2UH146FA0 A2UC146FA0
263230 THERMISTOR ASSEMBLY 6323A20023G R
430410 BASE ASSY,OUTDOOR 2H02079T 2H02079T R
435301 GRILLE,DISCHARGE 1H00840C 1H00840C R
437211 PANEL ASSEMBLY,FRONT(OUTDOOR) 2H02674S 2H02674S R
435512 COVER ASSY,TOP(OUTDOOR) 3H03465D 3H03465D R
437212 PANEL ASSY,REAR 1H00697N 1H00697N R
447910 BARRIER ASSY,OUTDOOR 3H03466F 3H03466F R
546810 MOTOR ASSEMBLY,OUTDOOR 4681AR1392Q 1H00853D R
550140 ISOLATOR,COMP 4H00982E 4H00982E R
552111-1 TUBE ASSEMBLY,CAPILLARY 5211A10381C R
552111-2 TUBE ASSEMBLY,CAPILLARY 5211A10381A R
552115 TUBE ASSEMBLY,MENIFOLD(OUTDOOR) 5211A20952C R
552116 TUBE ASSEMBLY,REVERSING 5211A10053C R
552117 TUBE ASSEMBLY,SUCTION(OUTDOOR) 5211A20935A R
552203-1 VALVE,SERVICE 2H02479H 2H02479H R
552203-2 VALVE,SERVICE 5220A20001J 5220A20001J R
559010 FAN ASSEMBLY,PROPELLER 5900AR1119B 5900AR1119B R
554031 CONDENSER ASSEMBLY,BENT 5403A20134C 5403A20134D R
554160 COMPRESSOR SET 2520UTGP2AA 2520UTGP2AA R
561410-1 COIL ASSEMBLY,SOLENOID 6141A20013F 6141A20013F R
561410-2 COIL ASSEMBLY,REVERSING VALVE 6141A20010B R
561410-3 COIL ASSEMBLY,SOLENOID 6141A20013D 6141A20013D R
561410-4 COIL ASSEMBLY,REVERSING VALVE 6141A20013G 6141A20013G R
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A20112H 4995A20112J R
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A20414H 6871A20414J R
W0CZZ CAPACITOR,DRAWING 2H01451S 2H01451T R
552114 TUBE ASSEMBLY, DISCHARGE 5211A20951A R
DESCRIPTION
SVC
CODE
LOCATION
No.
