74 Free Joint Multi Air Conditioner
Exploded View & Replacement Parts List
PART No.
A3UH216FA0 A3UC216FA0
135314 GRILLE,REAR 1A00207B R
137213-1 PANEL ASSEMBLY,SIDE 1A00201D R
137213-2 PANEL ASSY,SIDE 3A02284M R
263230 THERMISTOR ASSEMBLY 6323A20023A 6323A20023B R
430410 BASE ASSEMBLY,OUTDOOR 3041AP2741H 3041AP2741H R
435301 GRILL, DISCHARGE 3530A20007B R
435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3551A30088D 3551A30061G R
435512 COVER ASSEMBLY,TOP(OUTDOOR) 3551A30113B 3H03266K R
437211 PANEL ASSEMBLY, FRONT(OUTDOOR) 3721A23001A 3721A20005P R
437212 PANEL ASSY,REAR 3720AP0003F R
447910 BARRIER ASSEMBLY,OUTDOOR 4791A30004K 4791A30004K R
546810 MOTOR ASSEMBLY,OUTDOOR 4681A20028J 4681A20028J R
548490 ACCUMULATOR ASSEMBLY(MECH) 4849A20039A 4849A20042A R
550140 ISOLATOR,COMP 4H00982E 4H00982E R
552112 TUBE ASSEMBLY,CONDENSER IN 5211A01001B 5211A10458A R
552113 TUBE ASSEMBLY,CONDENSER OUT 5211A00001A 5211A00001B R
552114 TUBE ASSEMBLY,DISCHARGE (OUTDOOR) 5211A10456B R
552116 TUBE ASSEMBLY,REVERSING 5211A10445B R
552203-1 VALVE,SERVICE 5220A20001K 5220A20001K R
552203-2 VALVE,SERVICE 2H02479R 2H02479R R
554160-1 COMPRESSOR 5416A90022D 5416A90022D R
554160-2 COMPRESSOR 5416A90022B 5416A90022B R
561411-1 COIL ASSEMBLY,EXPANSION 6141A20018A 6141A20018A R
561411-2 COIL ASSEMBLY,EXPANSION 6141A20018B 6141A20018B R
561411-3 COIL ASSEMBLY,EXPANSION 6141A20018C 6141A20018C R
554031 CONDENSER ASSEMBLY,BENT 5403A20072N 5403A20072R R
559010 FAN ASSEMBLY,PROPELLER 5901A10032A 5901A10032A R
561410 COIL ASSEMBLY,REVERSING VALVE 6141A20010J R
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A10112C 4995A10112D R
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A20414D 6871A20414E R
738281 MANUAL,SERVICE 3828A20097X 3828A20097X R
738282 MANUAL,INSTALLATION 3828A20403H 3828A20403B R
738290 MANUAL,OWNERS 3828A20394A 3828A20394A R
W0CZZ-1 CAPACITOR,DRAWING 6120AR2194D 6120AR2194D R
W0CZZ-2 CAPACITOR,DRAWING 2H00841Z 2H00841Z R
DESCRIPTION
SVC
CODE
LOCATION
No.
