Service Manual 77
Exploded View & Replacement Parts List
PART No.
A4UH306FA0 A4UC306FA0
135301 GRILLE,DISCHARGE 3530A20006G 3530A20006G R
135314 GRILLE,REAR 3530A10176B 3530A10176B R
263230 THERMISTOR ASSEMBLY 6323A20023E 6323A20023F R
430410 BASE ASSY, OUTDOOR 3041AP7177D 3041AP7177D R
435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3551A30088F 3551A30088G R
435512 COVER ASSEMBLY,TOP(OUTDOOR) 3H03266H 3H03266H R
437211 PANEL ASSEMBLY,FRONT(OUTDOOR) 3721A10109A 3721A10109A R
447910 BARRIER ASSEMBLY,OUTDOOR 4791A10019B 4791A10019B R
546810 MOTOR ASSEMBLY,OUTDOOR 4681AR1392Y 4681AR1392Y R
552114 TUBE ASSEMBLY,DISCHARGE (OUTDOOR) 5211A11013A R
548490 ACCUMULATOR ASSEMBLY(MECH) 4849A10039A 4849A10039B R
550140 ISOLATOR,COMP 4H00982E 4H00982E R
552112 TUBE ASSEMBLY,CONDENSER IN 5211A11010A 5211A11010A R
552113 TUBE ASSEMBLY,CONDENSER OUT 5211A12001A 5211A12001B R
552116 TUBE ASSEMBLY,REVERSING 5211A10453A R
552117 TUBE ASSEMBLY,SUCTION(OUTDOOR) 5211A11012A 5211A11012A R
554031 CONDENSER ASSEMBLY,BENT 5403A20168B 5403A20168B R
559010 FAN ASSEMBLY,PROPELLER 5901A10033A 5901A10033A R
561410 COIL ASSEMBLY,REVERSING VALVE 6141A20010K R
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A10117A 4995A10117B R
668711 PWB(PCB) ASSEMBLY,MAIN(OUTDOOR) 6871A20414F 6871A20414G R
137213-1 PANEL ASSEMBLY,SIDE 3721A10110A 3721A10110A R
137213-2 PANEL ASSEMBLY,SIDE 3721A10111A 3721A10111A R
552203-1 VALVE,SERVICE 5220A20001K 5220A20001K R
552203-2 VALVE,SERVICE 2H02479R 2H02479R R
554160-1 COMPRESSOR 5416A90022E 5416A90022E R
554160-2 COMPRESSOR 5416A90022D 5416A90022D R
561411-1 COIL ASSEMBLY,EXPANSION 6141A20018D 6141A20018D R
561411-2 COIL ASSEMBLY,EXPANSION 6141A20018E 6141A20018E R
561411-3 COIL ASSEMBLY,EXPANSION 6141A20018F 6141A20018F R
561411-4 COIL ASSEMBLY,EXPANSION 6141A20018G 6141A20018G R
W0CZZ-1 CAPACITOR,DRAWING 0CZZA20007R 0CZZA20007R R
W0CZZ-2 CAPACITOR,DRAWING 2H01451V 2H01451V R
DESCRIPTION
SVC
CODE
LOCATION
No.
