LG A2UW166FA5 - 3. Piping Diagrams

- 4 -
Copyright ©2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
COOLING
HEATING
S-pipe
Sensor
Cond.
Ai r
Sensor
R/Valve
LEV-A
LEV-B
9.52
6.35
LEV 15RC
D-pipe
Sensor
Including
strainer
1.6*500
1.6*500
1.6*500
1.6*500
1.6*600
Strainer
GKT141DAA
(Inverter)
Sensor
LOC. Description PCB Connector
TH1 Thermistor for discharge pipe temperature
CN_TH2
TH2 Thermistor for suction pipe temperature
CN_TH2
TH3 Thermistor for outdoor air temperature CN_TH1
TH4 Thermistor for condensing temperature
CN_TH1
3. Piping Diagrams
