2. Specifications
13
MULTI/SINGLE Indoor unit
Wall Mounted Unit (2)
Model Name
S3NM18KL3BA
[SC18EQ NSK]
Power Supply V, Ø, Hz
220-240, 1, 50
220, 1, 60
Capacity
Cooling kW 5
Heating kW 5.8
Power Input Min./Nom./Max. W x No. 26 / 39 / 60
Running Current Min./Nom./Max. A 0.22 / 0.28 / 0.40
Casing Color - Munsell 7.5BG 10/2 (RAL 9016)
Dimensions
Body
W x H x D mm 998 x 345 x 210
W x H x D inch 39-9/32 x 13-19/32 x 8-9/32
Shipping
W x H x D mm 1,080 x 422 x 281
W x H x D inch 42-17/32 x 16-5/8 x 11-1/16
Weight
Body kg (lbs) 12.0 (26.5)
Shipping kg (lbs) 15.4 (34.0)
Heat Exchanger
(Row x Column x Fins per inch) x
No.
- (2 x 16 x 20) x 1
Face Area
m
2
(ft
2
)
0.28 (3.01)
Fan
Type - Cross Flow Fan
Air Flow Rate
H / M / L
m
3
/min
14.2 / 11.3 / 9.9
H / M / L
ft
3
/min
501 / 399 / 350
Fan Motor
Type - BLDC
Output W x No. 60 x 1
Sound Pressure Level H / M / L dB(A) 44 / 38 / 35
Sound Power Level Max. dB(A)
60
Piping Connections
Liquid mm(inch) Ø 6.35 (1/4)
Gas mm(inch) Ø 12.7 (1/2)
Drain O.D. / I.D. mm 21.5 / 16.0
Safety Devices
- Fuse
- Thermal Protector for Fan Motor
Connections Method - Flared
Power and Communication Cable (included Earth)
No. x mm
2
(AWG)
4C x 1.0 (18)
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national code. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound Level Values are measured at Anechoic chamber. Therefore, these values depend on the ambient conditions and values are normally higher
in actual operation.
4. Capacities are net capacities and based on the following conditions. Refer to the Outdoor Unit Specifications for calculating the real capacity.
• Cooling : Indoor Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• Heating : Indoor Ambient Temp. 20°CDB / 15°CWB, Outdoor Ambient Temp. 7°CDB / 6°CWB
• Interconnected Pipe is standard length and difference of Elevation (Outdoor ~ Indoor Unit) is Zero.
