3. Piping Diagrams
Heat exchanger
Th3
Th1
Gas pipe connection port
(flare connection)
Th2
Liquid pipe connection port
(flare connection)
C.F.F
Cooling
Heating
LOC. Description PCB Connector
Th1 Thermistor for Inlet air temperature CN_TH1
Th2 Thermistor for Liquid line temperature CN_TH1
Th3 Thermistor for Gas line temperature CN_TH2
