MULTI V S Outdoor Unit
6. Capacity Tables
48
Product Data
100
-19.8 -20 9.8 5.27 9.8 5.24 9.7 5.18 9.7 5.18 9.7 5.18 9.5 5.14
-18.8 -19 10.0 5.26 10.0 5.23 10.0 5.21 10.0 5.17 10.0 5.14 9.8 5.05
-16.7 -17 10.4 5.23 10.4 5.20 10.4 5.25 10.4 5.14 10.4 4.95 10.2 4.86
-13.7 -15 11.2 5.19 11.2 5.16 11.1 5.14 11.1 4.86 11.1 4.68 10.9 4.59
-11.8 -13 11.5 5.16 11.5 5.14 11.5 4.95 11.5 4.69 11.5 4.51 10.9 4.42
-9.8 -11 11.9 5.14 11.9 4.93 11.9 4.75 11.9 4.51 11.7 4.34 10.9 4.24
-9.5 -10 12.0 5.10 12.0 4.89 11.9 4.72 11.9 4.48 11.7 4.31 10.9 4.21
-8.5 -9.1 12.2 4.99 12.2 4.79 12.2 4.63 12.1 4.39 11.7 4.22 10.9 4.12
-7 -7.6 12.8 4.82 12.7 4.63 12.5 4.48 12.1 4.25 11.7 4.09 10.9 3.99
-5 -5.6 13.3 4.60 13.2 4.42 12.5 4.28 12.1 4.07 11.7 3.91 10.9 3.81
-3 -3.7 13.7 4.38 13.3 4.21 12.5 4.08 12.1 3.88 11.7 3.73 10.9 3.63
0 -0.7 14.1 4.04 13.3 3.89 12.5 3.79 12.1 3.61 11.7 3.46 10.9 3.36
3 2.2 14.1 3.70 13.3 3.58 12.5 3.49 12.1 3.33 11.7 3.19 10.9 3.09
5 4.1 14.1 3.48 13.3 3.37 12.5 3.30 12.1 3.15 11.7 3.02 10.9 2.91
7 6 14.1 3.26 13.3 3.15 12.5 3.10 12.1 2.97 11.7 2.84 10.9 2.73
9 7.9 14.1 3.09 13.3 2.99 12.5 2.94 12.1 2.81 11.7 2.69 10.9 2.59
11 9.8 14.1 2.94 13.3 2.85 12.5 2.80 12.1 2.68 11.7 2.56 10.9 2.47
13 11.8 14.1 2.79 13.3 2.70 12.5 2.66 12.1 2.54 11.7 2.43 10.9 2.34
15 13.7 14.1 2.63 13.3 2.55 12.5 2.50 12.1 2.40 11.7 2.29 10.9 2.20
90
-19.8 -20 9.7 4.85 9.7 4.91 9.7 4.96 9.7 4.98 9.7 4.81 9.5 4.59
-18.8 -19 10.0 4.87 10.0 4.93 9.9 4.98 9.9 4.89 9.9 4.73 9.7 4.51
-16.7 -17 10.4 4.91 10.4 4.98 10.4 4.80 10.4 4.72 10.4 4.56 10.0 4.34
-13.7 -15 11.2 4.98 11.2 4.71 11.1 4.55 11.1 4.46 10.7 4.32 10.0 4.11
-11.8 -13 11.5 4.79 11.5 4.54 11.4 4.39 11.1 4.30 10.7 4.16 10.0 3.96
-9.8 -11 11.9 4.60 11.9 4.37 11.4 4.22 11.1 4.13 10.7 4.00 10.0 3.80
-9.5 -10 12.0 4.57 12.0 4.34 11.4 4.20 11.1 4.11 10.7 3.98 10.0 3.78
-8.5 -9.1 12.2 4.47 12.1 4.25 11.4 4.11 11.1 4.02 10.7 3.89 10.0 3.70
-7 -7.6 12.8 4.33 12.1 4.12 11.4 3.99 11.1 3.90 10.7 3.77 10.0 3.58
-5 -5.6 12.9 4.14 12.1 3.94 11.4 3.82 11.1 3.73 10.7 3.61 10.0 3.42
-3 -3.7 12.9 3.94 12.1 3.77 11.4 3.65 11.1 3.56 10.7 3.45 10.0 3.27
0 -0.7 12.9 3.65 12.1 3.50 11.4 3.40 11.1 3.30 10.7 3.20 10.0 3.03
3 2.2 12.9 3.36 12.1 3.24 11.4 3.14 11.1 3.05 10.7 2.96 10.0 2.80
5 4.1 12.9 3.17 12.1 3.06 11.4 2.98 11.1 2.88 10.7 2.79 10.0 2.64
7 6 12.9 2.98 12.1 2.88 11.4 2.81 11.1 2.71 10.7 2.63 10.0 2.48
9 7.9 12.9 2.80 12.1 2.71 11.4 2.64 11.1 2.55 10.7 2.47 10.0 2.33
11 9.8 12.9 2.62 12.1 2.54 11.4 2.47 11.1 2.39 10.7 2.32 10.0 2.18
13 11.8 12.9 2.44 12.1 2.37 11.4 2.30 11.1 2.22 10.7 2.16 10.0 2.04
15 13.7 12.9 2.26 12.1 2.19 11.4 2.13 11.1 2.06 10.7 2.00 10.0 1.89
80
-19.8 -20 9.6 4.28 9.6 4.35 9.6 4.41 9.6 4.27 9.6 4.07 8.9 3.88
-18.8 -19 9.9 4.31 9.9 4.41 9.9 4.34 9.9 4.19 9.6 4.00 8.9 3.81
-16.7 -17 10.2 4.41 10.2 4.25 10.2 4.18 9.9 4.04 9.6 3.85 8.9 3.67
-13.7 -15 10.2 4.18 10.2 4.03 10.2 3.95 9.9 3.82 9.6 3.65 8.9 3.48
-11.8 -13 10.2 4.03 10.2 3.88 10.2 3.81 9.9 3.68 9.6 3.51 8.9 3.35
-9.8 -11 10.2 3.87 10.2 3.73 10.2 3.66 9.9 3.53 9.6 3.38 8.9 3.22
-9.5 -10 10.3 3.84 10.3 3.71 10.2 3.64 9.9 3.51 9.6 3.36 8.9 3.20
-8.5 -9.1 10.9 3.76 10.9 3.63 10.2 3.56 9.9 3.43 9.6 3.29 8.9 3.13
-7 -7.6 11.6 3.64 10.9 3.52 10.2 3.45 9.9 3.32 9.6 3.18 8.9 3.04
-5 -5.6 11.6 3.49 10.9 3.37 10.2 3.30 9.9 3.17 9.6 3.04 8.9 2.90
-3 -3.7 11.6 3.33 10.9 3.22 10.2 3.14 9.9 3.03 9.6 2.91 8.9 2.77
0 -0.7 11.6 3.09 10.9 2.99 10.2 2.92 9.9 2.81 9.6 2.70 8.9 2.57
3 2.2 11.6 2.85 10.9 2.76 10.2 2.69 9.9 2.58 9.6 2.49 8.9 2.38
5 4.1 11.6 2.69 10.9 2.61 10.2 2.54 9.9 2.44 9.6 2.35 8.9 2.25
7 6 11.6 2.54 10.9 2.46 10.2 2.39 9.9 2.29 9.6 2.21 8.9 2.11
9 7.9 11.6 2.38 10.9 2.31 10.2 2.24 9.9 2.15 9.6 2.08 8.9 1.99
11 9.8 11.6 2.21 10.9 2.15 10.2 2.08 9.9 2.00 9.6 1.93 8.9 1.84
13 11.8 11.6 2.06 10.9 2.00 10.2 1.94 9.9 1.86 9.6 1.80 8.9 1.72
15 13.7 11.6 1.94 10.9 1.89 10.2 1.83 9.9 1.75 9.6 1.70 8.9 1.62
Combination
(%)
Outdoor air temp
Indoor air temp. ℃ DB
16 18 20 21 22 24
℃ DB ℃ WB
TC PI TC PI TC PI TC PI TC PI TC PI
