8. Electrical Wiring
26
Installation of Outdoor Units
 Main PCB (Standard model)
 Display PCB (Compact model)
CAUTION
Product may not properly operate if the relevant DIP switch is not properly setup.
SW04C (× : cancel)
SW03C (▶ : forward)
DIP-SW01 7 - Segment
SW02C (◀ : backward)
SW01C (● : confirm)
SW01D (reset)
DIP SWITCH
7-Segment
SW01C (
: confirm)
SW02C (
: backward)
SW04C ( X : cancel)
SW01D (reset)
SW03C (
: forward)
