6. Capacity Tables
55
MULTI V S Outdoor Unit
Product Data
Note
1. TC: Total Capacity(kW), PI : Power Input(kW, Comp. + Outdoor fan motor)
2. Capacity tables show the average value of conditions which may occur.
70
-19.8 -20 12.2 5.78 11.8 5.81 11.1 5.60 10.8 5.31 10.4 5.05 9.7 4.79
-18.8 -19 12.5 5.81 11.8 5.70 11.1 5.49 10.8 5.21 10.4 4.95 9.7 4.70
-16.7 -17 12.5 5.58 11.8 5.47 11.1 5.27 10.8 5.00 10.4 4.76 9.7 4.51
-13.7 -15 12.5 5.25 11.8 5.14 11.1 4.95 10.8 4.70 10.4 4.48 9.7 4.25
-11.8 -13 12.5 5.04 11.8 4.93 11.1 4.75 10.8 4.51 10.4 4.30 9.7 4.08
-9.8 -11 12.5 4.82 11.8 4.71 11.1 4.54 10.8 4.31 10.4 4.12 9.7 3.90
-9.5 -10 12.5 4.79 11.8 4.68 11.1 4.51 10.8 4.28 10.4 4.09 9.7 3.87
-8.5 -9.1 12.5 4.68 11.8 4.57 11.1 4.40 10.8 4.18 10.4 4.00 9.7 3.78
-7 -7.6 12.5 4.52 11.8 4.40 11.1 4.24 10.8 4.03 10.4 3.86 9.7 3.65
-5 -5.6 12.5 4.30 11.8 4.18 11.1 4.03 10.8 3.83 10.4 3.67 9.7 3.47
-3 -3.7 12.5 4.08 11.8 3.96 11.1 3.82 10.8 3.64 10.4 3.49 9.7 3.29
0 -0.7 12.5 3.75 11.8 3.63 11.1 3.50 10.8 3.34 10.4 3.21 9.7 3.03
3 2.2 12.5 3.42 11.8 3.30 11.1 3.19 10.8 3.04 10.4 2.93 9.7 2.76
5 4.1 12.5 3.20 11.8 3.08 11.1 2.97 10.8 2.84 10.4 2.74 9.7 2.58
7 6 12.5 2.98 11.8 2.86 11.1 2.76 10.8 2.64 10.4 2.56 9.7 2.40
9 7.9 12.5 2.69 11.8 2.58 11.1 2.49 10.8 2.38 10.4 2.31 9.7 2.17
11 9.8 12.5 2.50 11.8 2.40 11.1 2.32 10.8 2.22 10.4 2.15 9.7 2.02
13 11.8 12.5 2.34 11.8 2.25 11.1 2.17 10.8 2.07 10.4 2.01 9.7 1.89
15 13.7 12.5 2.21 11.8 2.12 11.1 2.05 10.8 1.96 10.4 1.90 9.7 1.78
60
-19.8 -20 10.8 5.73 10.2 5.50 9.6 5.20 9.2 4.91 8.9 4.65 8.3 4.39
-18.8 -19 10.8 5.61 10.2 5.39 9.6 5.09 9.2 4.82 8.9 4.56 8.3 4.30
-16.7 -17 10.8 5.37 10.2 5.15 9.6 4.87 9.2 4.61 8.9 4.36 8.3 4.12
-13.7 -15 10.8 5.02 10.2 4.81 9.6 4.55 9.2 4.31 8.9 4.09 8.3 3.85
-11.8 -13 10.8 4.81 10.2 4.60 9.6 4.35 9.2 4.12 8.9 3.91 8.3 3.68
-9.8 -11 10.8 4.58 10.2 4.37 9.6 4.14 9.2 3.93 8.9 3.73 8.3 3.51
-9.5 -10 10.8 4.54 10.2 4.34 9.6 4.11 9.2 3.90 8.9 3.70 8.3 3.48
-8.5 -9.1 10.8 4.43 10.2 4.22 9.6 4.00 9.2 3.80 8.9 3.61 8.3 3.39
-7 -7.6 10.8 4.25 10.2 4.05 9.6 3.84 9.2 3.65 8.9 3.47 8.3 3.26
-5 -5.6 10.8 4.02 10.2 3.83 9.6 3.63 9.2 3.45 8.9 3.28 8.3 3.08
-3 -3.7 10.8 3.79 10.2 3.60 9.6 3.42 9.2 3.25 8.9 3.10 8.3 2.91
0 -0.7 10.8 3.45 10.2 3.26 9.6 3.10 9.2 2.96 8.9 2.82 8.3 2.64
3 2.2 10.8 3.10 10.2 2.93 9.6 2.78 9.2 2.66 8.9 2.54 8.3 2.38
5 4.1 10.8 2.87 10.2 2.70 9.6 2.57 9.2 2.46 8.9 2.36 8.3 2.20
7 6 10.8 2.64 10.2 2.47 9.6 2.36 9.2 2.27 8.9 2.17 8.3 2.02
9 7.9 10.8 2.36 10.2 2.21 9.6 2.10 9.2 2.02 8.9 1.94 8.3 1.80
11 9.8 10.8 2.20 10.2 2.06 9.6 1.96 9.2 1.89 8.9 1.81 8.3 1.68
13 11.8 10.8 2.06 10.2 1.93 9.6 1.84 9.2 1.77 8.9 1.70 8.3 1.58
15 13.7 10.8 1.95 10.2 1.82 9.6 1.74 9.2 1.67 8.9 1.60 8.3 1.49
50
-19.8 -20 9.0 4.75 8.5 4.48 8.0 4.23 7.7 4.00 7.5 3.78 6.9 3.58
-18.8 -19 9.0 4.65 8.5 4.38 8.0 4.15 7.7 3.92 7.5 3.71 6.9 3.50
-16.7 -17 9.0 4.44 8.5 4.19 8.0 3.96 7.7 3.75 7.5 3.55 6.9 3.35
-13.7 -15 9.0 4.15 8.5 3.91 8.0 3.71 7.7 3.50 7.5 3.33 6.9 3.14
-11.8 -13 9.0 3.96 8.5 3.74 8.0 3.54 7.7 3.35 7.5 3.18 6.9 3.00
-9.8 -11 9.0 3.77 8.5 3.55 8.0 3.37 7.7 3.19 7.5 3.03 6.9 2.86
-9.5 -10 9.0 3.74 8.5 3.52 8.0 3.34 7.7 3.16 7.5 3.01 6.9 2.84
-8.5 -9.1 9.0 3.64 8.5 3.43 8.0 3.26 7.7 3.08 7.5 2.93 6.9 2.76
-7 -7.6 9.0 3.50 8.5 3.29 8.0 3.13 7.7 2.96 7.5 2.82 6.9 2.66
-5 -5.6 9.0 3.30 8.5 3.11 8.0 2.96 7.7 2.80 7.5 2.67 6.9 2.51
-3 -3.7 9.0 3.11 8.5 2.92 8.0 2.78 7.7 2.64 7.5 2.52 6.9 2.37
0 -0.7 9.0 2.81 8.5 2.64 8.0 2.52 7.7 2.39 7.5 2.30 6.9 2.15
3 2.2 9.0 2.52 8.5 2.37 8.0 2.27 7.7 2.15 7.5 2.07 6.9 1.94
5 4.1 9.0 2.33 8.5 2.18 8.0 2.09 7.7 1.99 7.5 1.92 6.9 1.79
7 6 9.0 2.13 8.5 1.99 8.0 1.92 7.7 1.82 7.5 1.77 6.9 1.65
9 7.9 9.0 1.92 8.5 1.80 8.0 1.73 7.7 1.65 7.5 1.60 6.9 1.49
11 9.8 9.0 1.80 8.5 1.69 8.0 1.62 7.7 1.54 7.5 1.49 6.9 1.39
13 11.8 9.0 1.69 8.5 1.58 8.0 1.52 7.7 1.45 7.5 1.40 6.9 1.31
15 13.7 9.0 1.60 8.5 1.50 8.0 1.44 7.7 1.37 7.5 1.33 6.9 1.24
Combination
(%)
Outdoor air temp
Indoor air temp. ℃ DB
16 18 20 21 22 24
℃ DB ℃ WB
TC PI TC PI TC PI TC PI TC PI TC PI
