Table 4:ZE/ZF Chassis Central Controllers
Integration
Solution
Name Model No.
Devices
per
Controller
Systems
per
Comm
Bus
Devices
per Comm
Bus
No. of
Comm
Bus
Ports
Power
Binary
Signals
Input/
Output
Description
BACnet
®
Gateway
PQNFB17C1 256 16
64 (128
with PDI
Premium)
4 24 VAC 10/4
Allow integration of LG equipment
for control and monitoring by open
protocol BACnet
®
and LonWorks
®
building automation and controls
systems.
LonWorks
®
Gateway
PLNWKB100 64 16 64 1 24 VAC 2/2
Before specifying or placing an order, refer to the V-Net Network Solution Engineering Product Data Book and review the detailed technical data provided to fully understand the capabilities and limitations of
these devices.
Before specifying or placing an order, refer to the V-Net Network Solution Engineering Product Data Book and review the detailed technical data provided to fully understand the capabilities and limitations of
these devices.
Central
Controller
Name Model No.
Devices
per
Controller
Systems
per Comm
Bus
Devices
per Comm
Bus
No. of
Comm
Bus Ports
Binary
Signals
Input/
Output
Power,
Conn
Description
AC Smart
Premium
PQCSW421E0A 128 16 128 1 2/2 24 VAC
Provides scheduling,
autochangeover,
setback, remote controller
lock, setpoint,range limit, run
time limit, web access, email
alarm notification, visual
floorplan navigation,
peak/demand control,
software device interlocking,
PDI integration, and AC
Manager Plus integration
advanced functionality in
addition to basic unit control
and monitoring.
AC Ez PQCSZ250S0 32 16 256 1
12 VDC,
ODU
Provides for scheduling in
addition to basic indoor unit
control and monitoring.
Advanced
Control
Platform(ACP)
Standard
PQCPA11A0E 256 16
64 (128
with PDI
Premium)
4
2/2 24 VAC
Provides for scheduling,
remote controller lock,
setpoint range limit, web
access, peak/demand
control, PDI integration,
and AC Manager Plus
integration advanced
functionality in addition to
basic unit control and
monitoring.
Advanced
Control
Platform (ACP)
Premium
PQCPB11A0E 256 16
64 (128
with PDI
Premium)
10/4 24 VAC
Table 5:ZE/ZF Chassis Integration Solutions
