Service Manual 61
Replacement Parts List
Parts List (Indoor)
LOCATION
DESCRIPTION
PART No.
REMARKS
No.
131410 CHASSIS ASSEMBLY 3141A20006C 3141A20006C 3141A20005G R
135311 GRILLE ASSEMBLY,DISCHARGE(INDOOR) 3531A10222C 3531A10222C 3531A10234T R
135312 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A21021D 3531A21021D 3531A21016D R
135314 GRILLE,INLET 3530A10140B 3530A10140B 3530A10141B R
135516 COVER ASSEMBLY,MOTOR 3551A20050H 3551A20050H 3551A20050A R
146811 MOTOR ASSEMBLY,STEP 4681A20055A 4681A20055A 4681A20055A R
152302 FILTER(MECH),A/C 5230A10005A 5230A10005A 5230A20014A R
152313 FILTER ASSEMBLY,DEODORIZER - - - R
159830 AIR CLEANER ASSEMBLY - - - R
159901 VANE,HORIZONTAL 5990A10005B 5990A10005B 5990A20007B R
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20257R 4995A20257B 4995A20258B R
263230 THERMISTOR ASSEMBLY 6323A20004K 6323A20004K 6323A20004K R
264110 POWER CORD ASSEMBLY 6411A20026D 6411A20026D 6411A20026A R
266090 H.V ASSEMBLY - - - R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20030Z 6711A20030Z 6711A20030Z R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A90476C 6871A90476C 6871A90476C R
268714-1 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20272R 6871A20272A 6871A20272A R
268714-2 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20310B 6871A20310G 6871A20309F R
342800 BEARING 4280A20004B 4280A20004B 4280A20004B R
346810 MOTOR ASSEMBLY,INDOOR 4681A20062N 4681A20062L 4681A20048R R
35211B TUBE ASSEMBLY,TUBING 5211A21046R 5211A21046R 5211A21046S R
352150 HOSE ASSEMBLY,DRAIN 5251AR2575F 5251AR2575F 5251AR2575F R
354212 EVAPORATOR ASSEMBLY,FIRST 5421A10024A 5421A10024A 5421A20086A R
359011 FAN ASSEMBLY,CROSS FLOW 5901A20007E 5901A20007E 5901A20007D R
733010 PLATE ASSEMBLY,INSTALL 3301A10003A 3301A10003A 1H00843A R
W0CZZ CAPACITOR,DRAWING 3H01487A 3H01487A 3H01487A R
W6640 PWB(PCB) ASSEMBLY,SUB 6871A20283A 6871A20283A 6871A20283A R
AS-H076QNA2 AS-H096QNA2 AS-H126RNA2
NOTE)
*
Please ensure GCSC since these parts may be changed depending upon the buyer's request.
(GCSC WEBSITE http://biz.LGservice.com)
To Next Page
