Service Manual 65
Replacement Parts List
Parts List (Outdoor)
LOCATION
DESCRIPTION
PART No.
REMARKS
No.
430410 BASE ASSY,WELD[OUTDOOR] 3041A20016A 3041A20016A R
435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3551A30023Q 3551A30023F R
437210 GRILLE ASSEMBLY,FRONT(OUTDOOR) 3720A10171A 3720A10171A R
437212 PANEL ASSEMBLY,REAR(OUTDOOR) 3720A10172A 3720A10172A R
447910 BARRIER ASSY,OUTDOOR 4790A10025B 4790A10025B R
546810 MOTOR ASSEMBLY,OUTDOOR 4681A20121B 4681A20121B R
550140 ISOLATOR,COMP 4H00982E 4H00982E R
552102-1 TUBE,CAPILLARY BEND 5210A20595F 5210A21238L R
552102-2 TUBE,CAPILLARY BEND - - R
552111 TUBE ASSEMBLY,CAPILLARY 5211A20133Z 5211A21143F R
552116 TUBE ASSEMBLY,REVERSING 5211A21027B - R
552201 VALVE,CHECK - - R
552202 VALVE,REVERSING 5220AR3084E - R
552203-1 VALVE,SERVICE 2H02479P 2H02479P R
552203-2 VALVE,SERVICE 5220A20040A 5220A20003B R
554031 CONDENSER ASSEMBLY,BENT 5403A20059F 5403A20045X R
554160 COMPRESSOR 5416A20013L 2520UKJP2BA R
559010 FAN ASSEMBLY,PROPELLER 5900AR1266C 5900AR1266C R
561410 COIL ASSEMBLY,REVERSING VALVE 3A02028Y - R
567502 O.L.P 6750A30001C 6750A30001C R
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A10032J 4995A10032X R
W0CZZ CAPACITOR,DRAWING 2H01451P 2H01451T R
435301 GRILE,DISCHARGE 3530A10059G 3530A10059G R
LS-H096QLA2 LS-C126RLA2
NOTE)
*
Please ensure GCSC since these parts may be changed depending upon the buyer's request.
(GCSC WEBSITE http://biz.LGservice.com)
