Service Manual 67
Replacement Parts List
Parts List (Outdoor)
LOCATION
DESCRIPTION
PART No.
REMARKS
No.
430410 BASE ASSY,WELD[OUTDOOR] 3041A20008K 3041A20008K 3041A20008K R
435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3551A30023D 3551A30023D 3551A30023D R
437210 GRILLE ASSEMBLY,FRONT(OUTDOOR) 3721A20027S 3721A20027L 3721A20027L R
437212 PANEL ASSEMBLY,REAR(OUTDOOR) 3721A20026G 3721A20026G 3721A20026G R
447910 BARRIER ASSY,OUTDOOR 4791A30002A 4791A30002A 4791A30002A R
546810 MOTOR ASSEMBLY,OUTDOOR 4681A20004S 4681A20004S 4681A20004S R
550140 ISOLATOR,COMP 4H00982E 4H00982E 4H00982E R
552102-1 TUBE,CAPILLARY BEND 5210A21147A 5210A21147A 5210A21147A R
552102-2 TUBE,CAPILLARY BEND 5210A21146K 5210A21146K 5210A21146K R
552111 TUBE ASSEMBLY,CAPILLARY - - - R
552116 TUBE ASSEMBLY,REVERSING 5211A20188S 5211A20188S 5211A20188S R
552201 VALVE,CHECK 3H01552C 3H01552C 3H01552C R
552202 VALVE,REVERSING 5220AR3084E 5220AR3084E 5220AR3084E R
552203-1 VALVE,SERVICE 2H02479P 2H02479P 2H02479P R
552203-2 VALVE,SERVICE 5220A20003B 5220A20003B 5220A20003B R
554031 CONDENSER ASSEMBLY,BENT 5403A20026B 5403A20026B 5403A20026B R
554160 COMPRESSOR 2520UMAP2LA 2520UMAP2LA 2520UMAP2LA R
559010 FAN ASSEMBLY,PROPELLER 5901A10004A 5901A10004A 5901A10004A R
561410 COIL ASSEMBLY,REVERSING VALVE 3A02028Y 3A02028Y 3A02028Y R
567502 O.L.P 6750U-L035A 6750U-L035A 6750U-L035A R
649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995A20083F 4995A20083F 4995A20083F R
W0CZZ CAPACITOR,DRAWING 2H01451P 2H01451P 2H01451P R
435301 GRILE,DISCHARGE 3530A20006B 3530A20006B 3530A20006B R
LS-H126RGA2 LS-H126RLA2 LS-H126RMA2
NOTE)
*
Please ensure GCSC since these parts may be changed depending upon the buyer's request.
(GCSC WEBSITE http://biz.LGservice.com)
