Appendix40
Appendix
6
Specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) (135 x 295 x 315) mm
Net Weight (Approx.) 3.7 kg
Operating temperature 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity 5 % to 90 %
Inputs/ Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
HDMI OUT (video/audio): 19 pin Type A, HDMI™ Connector
DIGITAL IN (OPTICAL): 3 V (p-p), Optical jack x 1
PORT. IN 0.6 Vrms (3.5 mm stereo jack)
System
Laser Semiconductor laser, wavelength: 650 nm
Signal system Standard NTSC color TV system
Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio More than 80 dB
Harmonic distortion 0.05 % at 1 W
Dynamic range More than 85 dB
Bus Power Supply 5 V
0
1 A
Amplier
Stereo mode 80 W + 80 W (4Ω at 1 kHz)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
DM2740-FB_DAGOILK_ENG.indd 40 2014-06-13 2:56:06
