USB FUNCTION
Check USB_5V.
Display “NO USB”.
YES
YES
Check USB_D+/D-
(R380,R381/
R382,R383).
YES
Plug-in usb device.
Check CN302.
NO
NO
YES
Display “READ”.
YES
Display “NO FILE”.
YES
Check USB jack (JK301/ JK302).
NO
Replace IC501.
NO
Check IC501
(Pin U7,U8/ A7,A8).
Check usb audio
fi
le in usb device
(MP3, WMA
fi
le is playable)
YES
2. DOUBLE USB FUNCTION
3-28
CDP ELECTRICAL TROUBLESHOOTIHG GUIDE
