LG CMS4550F - Appendix; General Specifications

5 Appendix
Appendix 35
Appendix
5
General specifications
General
Power requirements Refer to the main label.
Power consumption
Refer to the main label.
Networked standby : 0.4 W
(If all network ports are activated.)
Dimensions (W x H x D) (206 x 308 x 284) mm
Net Weight (Approx.) 3 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Bus Power Supply 5 V 0 500 mA
Inputs
AUX IN 2.0 Vrms (1 kHz, 0 dB), 75 Ω, RCA jack (L, R)
Port In 1.2 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier
Total Output 700 W
Front 230 W X 2 (3 Ω at 1 kHz)
Subwoofer 240 W (3 Ω at 1 kHz)
THD 20 %
CD
Frequency Response 100 to 20000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 75 dB
