Appendix 27
Appendix
5
General specifications
General
Power requirements Refer to main label
Power consumption Refer to main label
Dimensions (W x H x D) 285 x 395 x 381 mm
Net Weight (Approx.) 6.2 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply USB DC 5 V
0
500 mA
Inputs
AUX IN 2.0 Vrms (1 kHz, 0 dB), 600 , RCA jack (L, R) x 1
PORT. IN 1.2 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
AM Tuning Range 522 to 1 620 kHz, 520 to 1 710 kHz or 522 to 1 710 kHz
Amplier
Stereo mode 310 W + 310 W (4 at 1 kHz, THD 10%)
Surround
mode
Front 310 W x 2 (4 at 1 kHz, THD 10%)
Rear 180 W x 2 (8 at 1 kHz, THD 10%)
Subwoofer 310 W x 2 (4 at 1 kHz, THD 10%)
CD
Frequency Response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
