Connecting Electric Dryers (cont.)
USA only
w
WARNING






fire or death.





Three-wire connection for electric dryers: Direct wire

construction after January 1, 1996.

1. Remove 3
1

the wire. Strip 1 inch (2.5 cm) insulation from each

shape.
2. Remove the terminal block access cover on the upper
back of the dryer. Install a UL-listed strain relief into
the power cord through-hole; then thread the power
cable prepared in Step 1 through the strain relief.

conductor cable.

and reinstallation of the dryer.
3. Attach the two hot leads of the power cord to the
outer terminal block screws. Attach the neutral wire to
the center terminal block screw. Connect the external
ground (if required by local codes) to the green
ground screw. .
Reinstall the terminal block access cover.
1" (2.5 cm)
UL-Listed
Strain Relief
UL-Listed 3-Wire
Power Cord
Terminal

Ground
Screw
Neutral
(White)
Hot

Hot
(Red)
External Ground
Wire (If required
by local codes)
White Wire
from Dryer
harness
INSTALLATION INSTRUCTIONS
