37
OPERATION
ENGLISH
There are three available positions for adjusting
the height of the upper rack to create more space.
Lowering the Rack
Hold the rack at the centre of each side to support
its weight. Then, push the button on each side to
release the rack and lower it to the lower position.
Raising the Rack
Lift the rack at the centre of each side until the rack
locks into place in the upper position. It is not
necessary to lift the lock levers to raise the rack.
Possible plate size according to the
upper rack position
• Before adjusting, ensure the rack is empty of all
dishes. Otherwise dishes may get damaged or
you may get injured.
• Raise the upper rack without pushing the
buttons on each side. Pushing the buttons when
raising the rack will prevent the rack from
locking into position.
Upper
Rack
Position
Plate Size (mm)
Upper Rack
Lower
Rack
with
Cutlery
Rack
without
Cutlery
Rack
Upper 165 215 300
Middle 193 243 272
Lower 221 271 244
