15INSTALLATION
ENGLISH
door aside face down on a protected
surface to prevent damage to the door or
the work surface.
3 Reverse the components on the cabinet.
1) Use a phillips screwdriver to remove the
two screws and the latch mechanism
a
on the front panel of the cabinet.
2) Remove the latch hole cover b by gently
prying it up with a flat blade screwdriver,
being careful not to scratch the paint.
Install the latch hole cover on the
opposite side, where the latch mechanism
was removed. Install the latch mechanism
in the position from which you removed
the latch hole cover, using the two screws
removed in a previous step.
3) Remove the hinge cover
c by gently
prying it up with a flat blade screwdriver,
being careful not to scratch the paint.
Rotate the hinge cover 180 degrees and
install it on the opposite side d, where
the hinge was attached.
4 With the door on a protected surface, remove
all screws on each side of the door and lift off
the inner door frame e using a flat blade
screwdriver. Remove the latch hook
f and
blank g and install them on the opposite side.
5 Remove the 4 screws securing the hinges to
the door frame. Remove the two plastic cover
caps h. Reinstall the hinges i and cover caps
h on the opposite sides from which they were
removed.
6 With the hinges and cover caps in the new
locations, remount the inner door frame onto
the outer door frame with the screws
removed in step 4 above.
• Be sure to support the weight of the door before
removing the hinge screws.
7 Reinstall the door.
• While supporting the door, install the four
hinge screws removed in step 2. Test the
swing of the door to make sure the hinges
and latch are properly aligned and that the
door opens, closes and latches properly in
both directions.
Easy load door (on some model)
• Be sure to support the weight of the door before
installing the hinge screws.
ON THE CABINET :
