20 INSTALLATION
different screws on the bottom edge, in the
locations marked below.
14 Now, pick up the upper hinge pivot removed
earlier and rotate it 180 degrees. Install the
hinge on the top left side of the cabinet.
※ A detailed diagram and identification of the inner structure and parts of the door
d Interlock buttons e Lower hinge filler f Side lock rod g Top lock rod
h Inner lock rods i Low hinge bracket j Hole plug k Lower hinge assembly
