LG DLE3170W Service Manual

2
To avoid injury to persons disconnect power before servicing this product. If electrical power is required
for diagnosis or test purposes, disconnect the power immediately after performing the necessary checks.
!
WARNING !
WHAT TO DO IF YOU SMELL GAS:
IMPORTANT SAFETY NOTICE
The information in this service guide is intended for use by individuals possessing skill and experience in
electrical, electronic, and mechanical appliance repair. Any attempt to repair a major appliance may result
in personal injury and property damage. The manufacturer or seller cannot be responsible for the
interpretation of this information, nor can it assume any liability in connection with its use.
RECONNECT ALL GROUNDING DEVICES
If grounding wires, screws, straps, clips, nuts, or washers used to complete a path to ground are
removed for service, they must be returned to their original position and properly fastened.
IMPORTANT
Electrostatic Discharge (ESD) Sensitive Electronics
ESD problems are present everywhere. ESD may damage or weaken the electronic
control assembly. The new control assembly may appear to work well after repair is
finished, but failure may occur at a later date due to ESD stress.
એ
Use an anti-static wrist strap. Connect wrist strap to green ground connection point or unpainted
metal in the appliance.
- OR -
Touch your finger repeatedly to a green ground connection point or unpainted metal
in the appliance.
એ
Before removing the part from its package, touch the anti-static bag to a green ground connection
point or unpainted metal in the appliance.
એ
Avoid touching electronic parts or terminal contacts; handle electronic control assembly by edges only.
એ
When repackaging failed electronic control assembly in anti-static bag, observe above instructions.
ᵉ Do not try to light a match, or cigarette, or turn on
any gas or electrical appliance.
ᵉ Do not touch any electrical switches. Do not use any
phone in your building.
ᵉ Clear the room, building or area of all occupants.
ᵉ Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions
carefully.
ᵉ If you cannot reach your gas supplier, call the fire
department.

LG DLE3170W Specifications

General

Door hinge	Right
Drum volume	209.5 L
Control type	Buttons, Rotary
Display type	LED
Loading type	Front-load
Drying system	-
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Cycle time	- min
Noise level	- dB
Drum capacity	10.2 kg
Number of drying levels	5
Number of drying programs	8
Current	30 A
Heat source	Electric
AC input voltage	240 V
Energy consumption	- kWh
Package depth	793.8 mm
Package width	794.3 mm
Package height	1073.2 mm
Package weight	65317 g

Weight and Dimensions

Depth	755.7 mm
Width	685.8 mm
Height	982.7 mm
Weight	58967 g
Depth with door open	1295.4 mm
