LG DLE3170W Service Manual

2
FEATURES AND BENEFITS
6
Open the door.
Hold the dryer rack
with both hands.
Put the dryer rack into
the drum
Check and be sure that the
front of the rack is properly
seated behind the lint filter.
3
INSTALLATION INSTRUCTIONS
Dryer Rack Installation Instructions

LG DLE3170W Specifications

General

Door hinge	Right
Drum volume	209.5 L
Control type	Buttons, Rotary
Display type	LED
Loading type	Front-load
Drying system	-
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Cycle time	- min
Noise level	- dB
Drum capacity	10.2 kg
Number of drying levels	5
Number of drying programs	8
Current	30 A
Heat source	Electric
AC input voltage	240 V
Energy consumption	- kWh
Package depth	793.8 mm
Package width	794.3 mm
Package height	1073.2 mm
Package weight	65317 g

Weight and Dimensions

Depth	755.7 mm
Width	685.8 mm
Height	982.7 mm
Weight	58967 g
Depth with door open	1295.4 mm
