( P/N : EBR62707645(Electric)
EBR62707646(Gas))
Main PCB Picture
<Electric>
Tab relay(Blue)
Tab relay(Black)
Tab relay(White)
YL3
BL2
NA4
NA6BL6
<Gas>
Tab relay(Blue)
Tab relay(Black)
YL3
BL2
NA4
BL3
NA6BL6
