PANEL DRAWER ASSEMBLY
1.
Pull out the drawer
2.
Lift out the steam feeder
.
3.
Lift the hook and pull out the drawer.
49
1.
Remove 2 screws on the frame body.
PCB ASSEMBLY
2.
Open the cover guide and disconnect the connectors.
