Page #52 background imageLoading...
Page #52 background image
Remove 3 screws on the frame body.
Push the guide assembly to the back
side and then lift it.
Separate 2 hoses from the pump and
generator.
Lift a pump and generator up.
GUIDE ASM
GUIDE ASM
52
