LG DLGX3701W Service Manual

49
12
DISASSEMBLY INSTRUCTIONS
TOP PLATE
2.
Push the top plate backward.
3.
Lift the top plate.
Unplug the dryer before servicing.
WARNING !
When you disassemble the top plate, be
sure to disconnect the dryer from its
electrical supply. Protect your hands and
arms from sharp edges when working.
To reduce the risk of Injury to persons
adhere to all industry recommended
safety procedures including the use of
long sleeved gloves and safety glasses.
WARNING !
THE DRYER TOP PLATE IS VERY LARGE
AND HEAVY. Fallure to follow
instructions can result in damage to the
dryer, property damage or Injury to persons.
1.
Remove 2 screws on the upper plate.
48

LG DLGX3701W Specifications

General

Brand	LG
Model	DLGX3701W
Capacity	7.4 cu. ft.
Color	White
Steam Technology	Yes
Energy Star Certified	Yes
Steam Cycle	Yes
Sensor Dry	Yes
Optional Dryer Settings	Yes
Reversible Door	Yes
End-of-Cycle Signal	Yes
Control Type	Electronic
Display Screen	LED
Stackable	Yes
Dryer Venting	Vented
