CHANGE GAS SETTING (NATURAL GAS, PROPANE GAS)
Natural Gas mode is set. Propane Gas Orifice is on sale as a Service
Part to authorized servicers only.
STEP 1 : VAL VE SETTING
STEP 2 : ORIFICE CHANGE
Natural Gas
Propane Gas
4948EL4001B
4948EL4002C
Kit contents: Orifice (Dia. = 1.47 mm, for Propane Gas)
Replacement Label
Instruction Sheet
NCU
PCK
Remove 2 screws.
Disassemble the pipe assembly.
Replace natural gas orifice with propane gas orifice.
Opened
Closed
Full open
Adjustment screw
Close
Adjustment screw
Orifice
Initially,
jGGGGGGGGGG
GVGUGjGGGGGGG

!
Warning
The burner is set for natural gas at the factory. The propane orifice
conversion kit is sold as a service part to autherized servicers only.
Part numbers are shown below.
FOR LG TECHNICIAN
46
GAS IGNITION
START
GAS IGNITION
ON
ON OFF
OFF ON
CLOSE
}hs}lGX
pnup{ly
}hs}lGY
mshtl
kl{lj{
OPEN
GAS VAL VE STRUCTURE
Adjustment Screw
GAS VALVE FLOW
START KEY PUSH
DRYING
)FFO 2 EVLAV( NO 1 EVLAV
VALVE 2 ON
IGNITER ON
FLAME DETECT OPEN
IGNITER
TEMPERATURE ABOUT
GAS IGNITION
FLAME DETECT CLOSE
VALVE 2 OFF
uv
uv
lz
lz
FOR LG TECHNICIAN
47
