12
DISASSEMBLY INSTRUCTIONS
TOP PLATE
2.
Push the top plate backward.
3.
Lift the top plate.
Unplug the dryer before servicing.
WARNING !
When you disassemble the top plate, be
sure to disconnect the dryer from its
electrical supply. Protect your hands and
arms from sharp edges when working.
To reduce the risk of Injury to persons
adhere to all industry recommended
safety procedures including the use of
long sleeved gloves and safety glasses.
WARNING !
THE DRYER TOP PLATE IS VERY LARGE
AND HEAVY. Fallure to follow
instructions can result in damage to the
dryer, property damage or Injury to persons.
1.
Remove 3 screws on the upper plate.
FOR LG TECHNICIAN
2.
.
3.
Lift the hook and pull out the drawer.
1.
Remove 2 screws on the frame body.
2.
Open the cover guide and disconnect the connectors.
1.
To Next Page
