75
Appendix
Specifications
General
Power Requirement Refer to the main label.
Power Consumption Refer to the main label.
Dimensions (W x H x D)
Approx. 1200.0 mm x 63.0 mm x 135.0 mm (including the base)
(47.2 inch x 2.5 inch x 5.3 inch)
Operation Temperature Range 5 °C - 40 °C (41 °F to 104 °F)
Operation Humidity Range 5 % - 60 % RH
Bus Power Supply (USB)
5 V 0 500 mA
Available Digital Input Audio Sampling
Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Available Digital Input Audio format
Dolby Digital, Dobly Digital Plus, Dolby TrueHD, Dolby Atmos,
DTS Digital Surround, DTS-HD HRA, DTS-HD MA, DTS:X, IMAX DTS,
IMAX DTS:X, PCM
Input/Output
OPTICAL IN 3.0 V (p-p), (optical audio connection terminal) × 1
HDMI IN 19-pin (Type A, HDMI™ connection terminal) × 1
HDMI d TV (eARC / ARC)
19-pin (Type A, HDMI™ connection terminal) × 1
4K resolution is supported for 4K sources applied with HDCP 2.3
(supported 4K@120 Hz (YCbCr 4:2:0)).
Amplier (RMS output)
Total 570 W RMS
Front 45 W RMS×2 (Impedance: 4 Ω, THD 10 %)
Center 40 W RMS (Impedance: 4 Ω, THD 10 %)
Surround (Side) 45 W RMS×2 (Impedance: 4 Ω, THD 10 %)
Top 45 W RMS×2 (Impedance: 4 Ω, THD 10 %)
Top center 40 W RMS (Impedance: 4 Ω, THD 10 %)
Subwoofer 220 W RMS (Impedance: 3 Ω, THD 10 %)
