LG EC93 Series Service Manual

- 6 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
1. Application range
This specification is applied to the OLED TV used ED42D
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
(1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F), CST: 40 °C ± 5 °C
(2) Relative Humidity: 65 % ± 10 %
(3) Power Voltage
: Standard input voltage (AC 100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC : CE, IEC
4. Model General Specification
No. Item Specication Remarks
1 Market EU(PAL Market-37Countries) DTV & Analog (Total 37 countries)
DTV (MPEG2/4, DVB-T) : 26 countries
Germany, Netherland, Switzerland, Hungary, Austria, Slovenia,
Bulgaria, France, Spain, Belgium, Luxemburg, Greece, Czech,
Croatia, Turkey, Morocco, Ireland, Latvia, Estonia, Lithuania, Poland,
Portugal, Romania, Albania, Bosnia, Slovakia, Belarus
DTV (MPEG2/4, DVB-T2): 11 countries
UK(Ireland), Sweden, Denmark, Finland, Norway, Ukraine, Kaza-
khstan, Russia, Italy, Croatia, Serbia
DTV (MPEG2/4, DVB-C): 37 countries
Germany, Netherland, Switzerland, Hungary, Austria, Slovenia,
Bulgaria, France, Spain, Italy, Belgium, Russia, Luxemburg, Greece,
Czech, Croatia, Turkey, Morocco, Ireland, Latvia, Estonia, Lithuania,
Poland, Portugal, Romania, Albania, Bosnia, Serbia, Slovakia, Bela-
rus, UK, Sweden, Denmark, Finland, Norway, Ukraine, Kazakhstan
DTV (MPEG2/4, DVB-S): 37 countries
Germany, Netherland, Switzerland, Hungary, Austria, Slovenia,
Bulgaria, France, Spain, Belgium, Luxemburg, Greece, Czech, Tur-
key, Morocco, Ireland, Latvia, Estonia, Lithuania, Poland, Portugal,
Romania, Albania, Bosnia, Slovakia, Belarus, UK(Ireland), Sweden,
Denmark, Finland, Norway, Ukraine, Kazakhstan, Russia, Italy,
Croatia, Serbia
Supported satellite : 35 satellites
ABS1 75.0E, AMOS 4.0W, ASIASAT3S 105.5E, ASTRA 19.2E,
ASTRA 23.5E, ASTRA 28.2E, ASTRA 4.8E, ATLANTIC BIRD2
8.0W, ATLANTIC BIRD3 5.0W, BADR 26.0E, DIRECTV-1R 56.0E,
EUROBIRD 9A 9.0E, EUROBIRD3 33.0E, EUTELSAT 36 A/B 36.0E,
EUTELSAT W2A 10.0E, EUTELSAT W3A 7.0E, EUTELSAT7WA
7.3W, EUTELSAT 16.0E, EXPRESS AM1 40.0E, EXPRESS AM3
140.0E, EXPRESS AM33 96.5E, HELLASSAT 39.0E, HISPASAT
1CDE 30.0W, HOTBIRD 13.0E, INTELSAT10&7 68.5E, INTELSAT15
85.2E, INTELSAT1R 50.0W, INTELSAT903 33.5W, INTELSAT904
60.0E, NILESAT 7.0W, NSS12 57.0E, THOR 0.8W, TURKSAT
42.0E,YAMAL201 90.0E, OTHER
