31
Is the resistance of the Thermistor out of range
2.5~180KΩ at 105~0°C?
Disassemble the Cabinet cover and Condensing
Bellows.
Is there any foreign object in Condensing Bellows?
Disassemble the Dry Fan Assy and Dry Duct Upper,
and clean foreign object in Duct and Fan.
Is the Connector connected correctly to
the Main PCB and the Dry Heater or Fan Motor?
Or is the Harness alright?
Reconnect or repair the Connector.
Or replace the Harness.
Replace the Thermistor.
Clean the Bellows.
YES
NO
Check for Dry Heater trouble. Page 24
Check for Dry Fan Motor trouble. Page 25
Dry Heater Error (dHE)
YES
YES
NO
NO
To Next Page
