DVD Mini Hi-Fi System ] USER GUIDE
5
Attaching the speakers to the unit
Connect the wires to the unit.
Match each wire’s coloured band to the same coloured connection terminal on
the reverse of the unit.
To connect the cable to the unit, press each plastic finger pad to open
the connection terminal. Insert the wire and release the finger pad
The connector will open ready to receive a cable.
Setting up
Connect the red end of each wire to the
terminals marked +(plus) and the black
end to the terminals marked - (minus).
Red
White
Front
Front
In front of you, to the right of
the screen
In front of you, to the left of
the screen
POSITION
SPEAKER
COLOUR
Remote control Operation
Point the Remote Control at the remote sensor and press the buttons.
Remote control Battery Installation
Detach the battery cover on the rear of the remote control, and insert two
R03 (size AAA) batteries with 3 and # aligned correctly.
Do not mix old and new batteries. Never mix different types of batteries
(standard, alkaline, etc.).
Be careful of the following
• Be careful to make sure children not to put their hands or any objects into the
speaker duct.
• Speaker duct : A hall for plentiful bass sound on speaker cabinet (enclosure).
