15
206-4290
FMA-LG102 Conguration (Cont.)
(Continued from previous page)
Set the FMA Broadcast Rate
The facility for setting the FMA broadcast rate is located on the right side of the FMA Configuration
Utility screen. The broadcast rate determines the interval, in seconds, at which to repeat the broadcast
of the date & time, the FTG Channel Map, and the FTG Installer Menu profile(s). (FMA-LG102 factory
default broadcast rate is 300 seconds.)
a. Click the down arrow at the right of the FMA Broadcast field, and select the number of seconds
(60 – 999) for the broadcast rate (“0” disables data broadcasting).
b. Click the Set Rate button to set the selected rate of broadcast in the FMA.
c. Once the system processes the request, a pop-up report message indicates success. Click OK to
close the pop-up window.
3. Click File and then Exit from the FTG Device Conguration Application menu bar to exit the FMA
Configuration Utility.
4. Connect the FMA-LG102 to the RF distribution system as described on page 11.
FMA-LG102 Conguration using the FMA-LG102 Software Web Page
1. Launch a web browser, and type http://ipaddress in the browser’s address bar, where ipaddress is
either the network IP address assigned by a DHCP server to the FMA-LG102 or the FMA-LG102’s
default IP address (see “FMA-LG102 Configuration Prerequisites” on page 13). Then, press Enter.
FMA-LG102 Software Web
Page Main Screen
Fields at the bottom left corner
of the screen identify the FMA-
LG102 firmware version, IP
address, and MAC address.
(Continued on next page)
