LG G1 User Manual

9
Securing TV to the Wall
1 Insert and tighten the eye-bolts, or TV brackets and bolts on the back of the TV.
• If there are bolts inserted at the eye-bolts position, remove the bolts first.
2 Mount the wall brackets with the bolts to the wall. Match the location of the wall bracket and the
eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly with a sturdy rope or cable. Make sure to keep
the rope parallel to the flat surface.
• Use a platform or cabinet that is strong and large enough to support the TV securely.
• Brackets, bolts and ropes are optional. You can obtain additional accessories from your local
dealer.
(Depending upon model)
Stand
(Depending upon model)
Stand Model
AP-G1DV55 OLED55G1*
AP-G1DV65 OLED65G1*
AP-G1DV77 OLED77G1*

LG G1 Specifications

General

Audio decoders	DTS Digital Surround, DTS-HD, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
Equalizer modes	Bass Blast, Bass Blast+
RMS rated power	360 W
Audio output channels	3.1 channels
Center speaker RMS power	40 W
Front speakers RMS power	100 W
Front speaker sensitivity	83 dB
Enhanced Audio Return Channel (eARC)	Yes
Subwoofer sensitivity	85 dB
Subwoofer connectivity	Wireless
Wi-Fi	No
HDCP version	2.3
Bluetooth codec	SBC / AAC
Bluetooth version	4.0
Connectivity technology	Wired & Wireless
Digital audio optical out	1
Product color	Black
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV, WMA
Consumer Electronics Control (CEC)	SimpLink
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Soundbar speaker RMS power	140 W
Package type	Box
Package depth	436 mm
Package width	1296 mm
Package height	251 mm
Package weight	15700 g
Harmonized System (HS) code	85182200

Weight and Dimensions

Depth	150 mm
Width	1225 mm
Height	32.5 mm
Soundbar weight	3400 g
Subwoofer depth	394 mm
Subwoofer width	180 mm
Subwoofer height	290 mm
Subwoofer weight	5800 g
