LG G5 Repair Guide

• Power on/off: To avoid any damage to the hardware during the repair, it is best to have the device
powered off until you can get to and disconnect the battery.
• Battery: Never unplug any flex cables unless the battery has been completely disconnected to avoid
frying your hardware. Do not plug the battery back until all cables have been reconnected.
• Release Screws: Apply pressure on the screw and twist counterclockwise to initially loosen it, then
lighten the pressure and continue twisting until the screw is gently released. Make sure you have
properly sized screwdrivers available for the repair.
• Pin Connectors: extremely fragile and must be plugged or unplugged with extreme caution.
• Battery connector: held down by light adhesive and solder. If not cautious it will come off the
motherboard. Very time consuming to be repaired. Do not break it in the first place.
• Motherboard: small surface mount components can be easily damaged if they are nicked by the
spudger. Always take your time and never touch the surface of the motherboard.
ADDITIONAL PRECAUTIONS

LG G5 Specifications

General

Screen shape	Flat
Pixel density	554 ppi
Second display	No
Display diagonal	5.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display number of colors	16.78 million colors
Processor cores	8
Processor family	Qualcomm Snapdragon
Processor frequency	1.8 GHz
Processor lithography	28 nm
Processor architecture	ARM Cortex-A53+Cortex-A72
RAM type	LPDDR3
RAM capacity	3 GB
RAM clock speed	933 MHz
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	2048 GB
Internal storage capacity	32 GB
Flash type	LED
Rear camera type	Dual camera
Front camera type	Single camera
Maximum frame rate	60 fps
Video recording modes	1080p, 2160p
Rear camera aperture number	1.8
Front camera aperture number	2
Rear camera resolution (numeric)	16 MP
Second rear camera aperture number	2.4
Second rear camera resolution (numeric)	8 MP
4G standard	LTE
2G standards	EDGE, GPRS
3G standards	HSPA+
SIM card type	NanoSIM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
SIM card capability	Single SIM
Mobile network generation	4G
Subscription type	No subscription
USB version	2.0
USB connector type	USB Type-C
HDMI ports quantity	0
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Color name	Titan
Form factor	Bar
Product color	Gray
Graphics card	Adreno 510
Audio formats supported	AC3, FLAC, MP4, OGG, WAV, WMA
Video formats supported	DIVX, H.263, H.264, MP4, WMV
Platform	Android
App distribution platform	Google Play
Operating system installed	Android 6.0
Talk time (3G)	- h
Battery capacity	2800 mAh
Head SAR (EU)	1.49 W/kg

Weight and Dimensions

Depth	7.7 mm
Width	73.9 mm
Height	149.4 mm
Weight	161 g
