Sliding pad Installation (Upper Dryer)
1) Leg removal
2) Leg bracket removal
3) Sliding pad installation
- Lay the upper dryer, set the bottom of the upper dryer.
- Remove the legs from the leg brackets.
- Loosen the black screw fixing the leg bracket.
- Remove the four(4) leg brackets from the bottom of upper dryer.
- There are eight(8) screw holes at both side of the bottom.
- Assemble the four(4) slide pads on the base.
- Tighten two(2) screws per each slide.
