LG GML945PZ8F User Manual

17
INSTALLATION
ENGLISH
- Spanner Type A
- Spanner Type B
Levelling the Appliance
The appliance has two front levelling legs. Adjust
the legs to alter the tilt from front to back or side to
side. If the appliance seems unsteady, or the doors
do not close easily, adjust the appliance’s tilt using
the instructions below.
It is quite normal for the appliance to have a
backward lean even when the front legs are turned
all the way.
Use the spanner
a to adjust the height by turning
the levelling leg to the left to raise it or to the right
to lower it.
Door Alignment for Freezer
Door
If the door of the appliance is not level, adjust the
difference in the height of appliance door.
1 Open the door and use the spanner a to
loosen the keeper nut by turning it to the left.
2 Use the spanner b to adjust the height by
turning the adjustment hinge pin to the left or
to the right.
CAUTION
• Do not adjust the height of the appliance door
more than 3 mm.

LG GML945PZ8F Specifications

General

Child lock	Yes
Door hinge	Left/right
Control type	Touch
Display type	LED
Product color	Silver
Product design	French door
Housing material	Metal
Shelves material	Tempered glass/Plastic
Appliance placement	Freestanding
Refrigerating medium	R600a
Door-in-Door function	No
Number of compressors	1
Fridge net capacity	368 L
Fridge door balconies	6
Fridge gross capacity	404 L
Fridge temperature range	1 - 7 °C
Number of vegetable drawers	2
Fridge number of shelves/baskets	4
Noise level	40 dB
Climate class	N-T
Cooling system	Dynamic (fan-assisted)
Water supply type	External water supply
Total net capacity	641 L
Total gross capacity	705 L
Minimum operating temperature	10 °C
Cord length	1.9 m
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	273 L
Freezer gross capacity	301 L
Freezer temperature (min)	-23 °C
Storage time during power failure	12 h
Current	1.8 A
Connected load	280 W
Power plug type	Type G
AC input voltage	230 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	450 kWh
Doesn't contain	Chlorofluorocarbon (CFC), Hydrofluorocarbon (HFC)
Package depth	808 mm
Package width	964 mm
Package height	1890 mm
Package weight	146000 g
Country of origin	South Korea
Number of drawers	2 drawer(s)
Dimensions (WxDxH)	912 x 744 x 1793 mm
Operating temperature (T-T)	16 - 43 °C
Quantity per pack	1 pc(s)
UK Trade Tariff code	8418102099

Weight and Dimensions

Depth	744 mm
Width	912 mm
Height	1793 mm
Weight	136000 g
Depth with door open	1104 mm
Width with door open	1699 mm
Installation compartment depth	669 mm
Installation compartment width	1012 mm
Installation compartment height	1840 mm
