LG GML945PZ8F User Manual

16
INSTALLATION
WARNING
• Connect to potable water supply only.
• Connecting the water line must only be installed
by a qualified plumber and in accordance with
local legislation and regulations governing
water quality.
NOTE
• This water line installation is not covered by the
appliance warranty.
Connecting Water to the
Appliance
1 Unscrew the metal threaded collar nut at the
back of the appliance and place it over one end
of the water tube.
2 Firmly push the water tube onto the water inlet
valve and tighten up the collar nut.
Connecting to the Water Tap
This feature is only available on some models.
1 Push the water tube into the hole of the tap
connector supplied in the accessories. The pipe
should be held firmly whilst the connector is
pushed onto the pipe.
2 Ensure that the rubber washer is fitted to the
inside of the tap connector before screwing it
onto the tap.
• A separate connector or adaptor may need
to be purchased if your tap fitting does not
match the thread size of the connector
provided.
Checking the Water Connection
1 Turn on the water supply and switch on the
appliance. Carefully check all fittings for
possible leaks due to poorly fitted hoses.
2 Press and hold the Water Filter button for
three seconds. The new water filter has been
activated.
3 Place a cup under the water dispenser to verify
that water is flowing through the appliance.
4 Check the connecting tube and joints for leaks
once again.
Levelling and Door
Alignment
Before Beginning
When the appliance doors appear to be uneven,
follow the instructions below to align the doors.
NOTE
• The spanner may differ depending on the model.
You will be provided with either spanner type A
or B.

LG GML945PZ8F Specifications

General

Child lock	Yes
Door hinge	Left/right
Control type	Touch
Display type	LED
Product color	Silver
Product design	French door
Housing material	Metal
Shelves material	Tempered glass/Plastic
Appliance placement	Freestanding
Refrigerating medium	R600a
Door-in-Door function	No
Number of compressors	1
Fridge net capacity	368 L
Fridge door balconies	6
Fridge gross capacity	404 L
Fridge temperature range	1 - 7 °C
Number of vegetable drawers	2
Fridge number of shelves/baskets	4
Noise level	40 dB
Climate class	N-T
Cooling system	Dynamic (fan-assisted)
Water supply type	External water supply
Total net capacity	641 L
Total gross capacity	705 L
Minimum operating temperature	10 °C
Cord length	1.9 m
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	273 L
Freezer gross capacity	301 L
Freezer temperature (min)	-23 °C
Storage time during power failure	12 h
Current	1.8 A
Connected load	280 W
Power plug type	Type G
AC input voltage	230 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	450 kWh
Doesn't contain	Chlorofluorocarbon (CFC), Hydrofluorocarbon (HFC)
Package depth	808 mm
Package width	964 mm
Package height	1890 mm
Package weight	146000 g
Country of origin	South Korea
Number of drawers	2 drawer(s)
Dimensions (WxDxH)	912 x 744 x 1793 mm
Operating temperature (T-T)	16 - 43 °C
Quantity per pack	1 pc(s)
UK Trade Tariff code	8418102099

Weight and Dimensions

Depth	744 mm
Width	912 mm
Height	1793 mm
Weight	136000 g
Depth with door open	1104 mm
Width with door open	1699 mm
Installation compartment depth	669 mm
Installation compartment width	1012 mm
Installation compartment height	1840 mm
