3. SENSOR RESISTANCE CHARACTERISTICS TABLE
¥ The tolerance of sensor resistance is ±5%.
¥ Be sure to measure the sensor resistance after keeping the sensor more than 3 minutes at a measuring temperature.
(It needs delay due to sensor speed.)
¥ Measure the resistances of SENSORs with a digital tester after disconnecting CON 4 of MAIN PWB ASSY.
- 28 -
MEASURED TEMPERATURE
RESISTANCE OF FREEZER SENSOR RESISTANCE OF DEFROST SENSOR, ROOM TEMPERATURE SENSOR
-20¡C 22.3k½ 77k½
-15¡C 16.9k½ 60k½
-10¡C 13.0k½ 47.3k½
-5¡C 10.1k½ 38.4k½
0¡C 7.8k½ 30k½
+5¡C 6.2k½ 24.1k½
+10¡C 4.9k½ 19.5k½
+15¡C 3.9k½ 15.9k½
+20¡C 3.1k½ 13k½
+25¡C 2.5k½ 11k½
+30¡C 2.0k½ 8.9k½
+40¡C 1.4k½ 6.2k½
+50¡C 0.8k½ 4.3k½
