14
Installation
Door replacement
Feed water pipe installation
Pass the refrigerator laterally through the access
door as shown in the right figure.
Automatic ice maker operation needs water pressure of 147~834 kPa
(1.5~8.5 kgf/cm
2
) (That is, an instant paper cup (180 cc) will be fully filled
within 3 sec.).
If water pressure does not reach the rating 147 kPa (1.5 kgf/cm
2
) or below, it is
necessary to purchase a separate pressure pump for normal automatic icing and cool
water feed.
Keep the total length of the feed water pipe tube within 8 m and be careful for the
tube not be bent. If the tube is 8 m or longer it may cause trouble in water feed owing
to the drain water pressure.
Install the feed water pipe tube at a place free from heat.
Connect to potable water supply only.
Refer to instructions with water filter kit for installation.
Mount them in the reverse sequence of removal after they pass through the access
door.
Pass the
refrigerator
Before
installation
To Next Page
