5. Supported video resolutions
5.1. 2D MODE
5.1.1. HDMI Input (PC/DTV)
No. Resolution H-freq (kHz) V-freq (Hz) Pixel clock (MHz) Proposed DDC
HDMI-PC
1 640*350 31.468 70.09 25.17 EGA X
2 720*400 31.469 70.08 28.32 PC98(DOS) O
3 640*480 31.469 59.94 25.17 VESA(VGA) O
4 800*600 37.879 60.31 40.00 VESA(SVGA) O
5 1024*768 48.363 60.00 65.00 VESA(XGA) O
6 1152*864 54.348 60.053 80.00 VESA(XGA+) O
7 1360*768 47.712 60.015 85.50 VESA(WXGA) O
8 1280*1024 63.981 60.02 108.0 VESA(SXGA) O
9 1920*1080 67.5 60.0 148.5 HDTV 1080P O
HDMI-DTV
1 720*480 31.47 60.0 27.027 SDTV 480P
2 720*480 31.47 59.94 27.00 SDTV 480P
3 720*480 31.50 60.0 27.027 SDTV 480P
4 1280*720 45.00 60.00 74.25 HDTV 720P
5 1280*720 44.96 59.94 74.176 HDTV 720P
6 1920*1080 33.75 60.00 74.25 HDTV 1080I
7 1920*1080 33.72 59.94 74.176 HDTV 1080I
8 1920*1080 67.50 60.0 148.50 HDTV 1080P
9 1920*1080 67.432 59.939 148.352 HDTV 1080P
10 1920*1080 27.000 24.000 74.25 HDTV 1080P
11 1920*1080 26.97 23.976 74.176 HDTV 1080P
12 1920*1080 33.75 30.000 74.25 HDTV 1080P
13 1920*1080 33.71 29.97 74.176 HDTV 1080P
