LG LB Series - Sensor Resistance Specifications

- 32 -
8-3 RESISTANCE SEPECIFICATION OF SENSOR
- The resistance of the SENSOR has a ±5% common difference.
- Measure the resistance of the SENSOR after leaving it for over 3 minutes in the measuring temperature.
This delay is necessary due to sensor response speed.
¥ Measure the F-SENSOR, SUPER FROST SENSOR, R1, R2-SENSOR after disconnect CON5 of PWB ASSY, MAIN.
TEMPERATURE DETECTED RESISTANCE OF FREEZER RESISTANCE OF REFRIGERATOR &
BY SENSOR SENSOR
DEFROST SENSOR & ROOM SENSOR
-20º C
-15º C
-10º C
- 5º C
0º C
+ 5º C
+ 10º C
+ 15º C
+ 20º C
+ 25º C
+ 30º C
+ 40º C
+ 50º C
22.3 K Ω
16.9 K Ω
13.0 K Ω
10.1 K Ω
7.8 K Ω
6.2 K Ω
4.9 K Ω
3.9 K Ω
3.1 K Ω
2.5 K Ω
2.0 K Ω
1.4 K Ω
0.8 K Ω
77 K Ω
60 K Ω
47.3 K Ω
38.4 K Ω
30 K Ω
24.1 K Ω
19.5 K Ω
15.9 K Ω
13 K Ω
11 K Ω
8.9 K Ω
6.2 K Ω
4.3 K Ω
