44 | FOUR-WAY CASSETTE
Four-Way Ceiling Cassette System Engineering Manual
Model No. /
Nominal Capacity
(Btu/h)
Outdoor Air Temp. Indoor Air Temp. °F DB
°F DB °F WB
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
LC187HV / 18,000
0 -0.4 8.96 1.12 8.42 1.16 8.43 1.18 8.24 1.19 8.08 1.20 7.74 1.24
5 4.5 10.89 1.14 10.37 1.18 10.23 1.20 10.01 1.22 9.84 1.23 9.44 1.27
10 9 12.18 1.15 11.69 1.19 11.43 1.22 11.20 1.24 11.01 1.25 10.58 1.29
17 15 13.60 1.17 13.13 1.21 12.75 1.25 12.50 1.27 12.30 1.29 11.83 1.32
20 19 14.46 1.19 14.00 1.22 13.55 1.27 13.29 1.29 13.08 1.31 12.59 1.35
25 23 15.90 1.22 15.43 1.25 14.89 1.30 14.61 1.32 14.38 1.35 13.84 1.38
30 28 17.34 1.25 16.80 1.29 16.22 1.33 15.93 1.36 15.69 1.38 15.11 1.42
35 32 18.78 1.28 18.18 1.33 17.56 1.36 17.24 1.39 16.99 1.42 16.38 1.45
40 36 19.73 1.32 19.18 1.36 18.57 1.40 18.25 1.43 17.99 1.45 17.34 1.49
45 41 20.93 1.36 20.43 1.41 19.83 1.45 19.50 1.48 19.24 1.50 18.54 1.55
47 43 21.41 1.38 20.93 1.43 20.33 1.47 20.00 1.50 19.73 1.52 19.02 1.57
50 46 21.47 1.37 21.04 1.42 20.52 1.46 20.22 1.48 19.98 1.50 19.31 1.54
55 51 21.58 1.36 21.22 1.39 20.83 1.43 20.59 1.44 20.40 1.46 19.79 1.49
60 56 21.68 1.35 21.40 1.37 21.14 1.40 20.95 1.41 20.81 1.42 20.28 1.44
63 59 21.74 1.34 21.51 1.36 21.32 1.38 21.18 1.39 21.06 1.39 20.57 1.41
68 64 21.81 1.33 21.62 1.34 21.51 1.36 21.40 1.36 21.31 1.37 20.86 1.38
Table 23: LC187HV System Heating Capacity Table.
Table 24: LC247HV System Heating Capacity Table.
Model No. /
Nominal Capacity
(Btu/h)
Outdoor Air Temp. Indoor Air Temp. °F DB
°F DB °F WB
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
LC247HV / 24,000
0 -0.4 15.86 1.74 14.97 1.81 14.92 1.83 14.59 1.85 14.32 1.86 13.72 1.93
5 4.5 17.72 1.80 16.91 1.86 16.65 1.90 16.30 1.92 16.01 1.94 15.37 2.00
10 9 18.97 1.85 18.21 1.91 17.80 1.96 17.44 1.98 17.15 2.01 16.48 2.07
17 15 20.35 1.91 19.64 1.97 19.07 2.04 18.70 2.07 18.40 2.10 17.69 2.16
20 19 21.18 1.96 20.50 2.02 19.84 2.09 19.46 2.13 19.16 2.16 18.43 2.22
25 23 22.57 2.04 21.90 2.10 21.14 2.18 20.74 2.22 20.42 2.26 19.65 2.32
30 28 23.96 2.13 23.22 2.20 22.42 2.27 22.01 2.32 21.68 2.36 20.88 2.42
35 32 25.35 2.22 24.54 2.30 23.71 2.36 23.28 2.41 22.94 2.46 22.11 2.52
40 36 26.64 2.28 25.89 2.36 25.07 2.43 24.63 2.48 24.29 2.52 23.41 2.59
45 41 28.26 2.37 27.58 2.44 26.77 2.52 26.32 2.57 25.97 2.60 25.02 2.68
47 43 28.90 2.40 28.26 2.48 27.45 2.56 27.00 2.60 26.64 2.64 25.67 2.71
50 46 28.99 2.38 28.40 2.45 27.70 2.52 27.30 2.56 26.98 2.59 26.07 2.66
55 51 29.13 2.36 28.65 2.42 28.12 2.47 27.79 2.50 27.54 2.52 26.72 2.58
60 56 29.27 2.33 28.89 2.38 28.53 2.42 28.29 2.44 28.09 2.45 27.38 2.49
63 59 29.35 2.32 29.03 2.35 28.78 2.39 28.59 2.40 28.43 2.41 27.77 2.44
68 64 29.44 2.30 29.18 2.33 29.04 2.36 28.89 2.36 28.77 2.37 28.17 2.39
TC = Total Capacity (kBtu/h).
PI = Power input (KW). Power input (KW) includes compressor and fan(s).
Nominal capacity as rated 0 ft. above sea level and a 0 ft. level difference between outdoor and indoor
unit. Corresponding refrigerant piping length is accordance with standard length of each outdoor unit.
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
60ºF wet bulb (WB), and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
TC = Total Capacity (kBtu/h).
PI = Power input (KW). Power input (KW) includes compressor and fan(s).
Nominal capacity as rated 0 ft. above sea level and a 0 ft. level difference between outdoor and indoor
unit. Corresponding refrigerant piping length is accordance with standard length of each outdoor unit.
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
60ºF wet bulb (WB), and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
PERFORMANCE DATA
Heating Capacity Tables
